APC Back UPS BK500EI

Item no. 19220501 Brand / Manufacturer APC Manuf. item no. BK500EI EAN 0731304016359 Item weight 6.453 kg
APC

Please log in to see our prices and to be able to order. Delivery only to industry, trade, crafts, public institutions, authorities and comparable institutions. No sale to private individuals!

Login
In stock - available for delivery within a few days

Description

Stromschutz für Büro- und Heimbürosysteme

Das Back-UPS CS bietet professionellen Stromschutz für Büro- und Heimbürosysteme. Batteriegestützte und überspannungsgeschützte Ausgänge, ein integrierter Schutz für Telefon-/Fax-/Modem-Leitungen, Software für den sicheren Shutdown des Systems mit fortschrittlichen Stromverwaltungsfunktionen sowie proaktive audio-visuelle Warnungen schützen Bürosysteme und wertvolle Daten vor Überspannungen, Spannungsspitzen und Stromausfällen. Das Back-UPS CS kann sowohl über USB als auch über eine serielle Schnittstelle angeschlossen werden und ermöglicht so eine schnelle und komfortable Installation. Die Wartung gestaltet sich ebenfalls komfortabel, da die Batterie während des Betriebs vom Nutzer ausgetauscht werden kann. Mit diesen Features bietet das Back-UPS CS einen idealen Schutz für Ihre Büro- und Heimbürosysteme.

Specifications

Manufacturer
APC
Product group
USV
Product type
UPS Offline
Colour
grey
Scope of delivery
USV, Software, Kabelsatz
Classification (IEC 62040-3)
VFD-SY-333
UPS technology
Offline
Output (VA/W)
500 / 300
Backup time full/half-load
4 / 7 min
Dimensions (HxWxD)
170 x 90 x 290 mm
Mounting form
Tower
Voltage (input)
196 - 280 V
Voltage (output)
230V
Frequency
50 Hz +- 3 %
Connector type (input)
Kaltgeräte IEC 320 C14
Connector type (output)
3 Kaltgeräte IEC 320 C13
Phase in/output
230V/230V / 50Hz
Over current protection
EMI,- RFI-Filter
Delay expansion unit
nein
Slot for adapter card
nein
Interface
DB-9 RS-232 , USB
RS-232 Interface
ja
USB 2.0 Interface
ja
Hot swap batteries
nein
Bypass
nein
Additional over current protector
Telefon/Fax
Activity LED
4 LED
Activity Display
nein
incl.Management Software
Windows
Internal cooling
passiv
Ambient temperature
0-40°C
Technical particularity
RS232 über Spezialkabel
Operating temperature min.
0 °C
Operating temperature max.
40 °C
Height
170 mm
Width
90 mm
Depth
290 mm
Weight
7 kg
Height of packaging (single piece)
240 mm
Width of packaging (single piece)
170 mm
Depth of packaging (single piece)
420 mm
Package weight (single piece)
6.453 kg
