APC Smart-UPS SRT 6000VA 230V Rack

Item no. 19293061 Brand / Manufacturer APC Manuf. item no. SRT6KRMXLI EAN 0731304308515 Item weight 70 kg
APC

Please log in to see our prices and to be able to order. Delivery only to industry, trade, crafts, public institutions, authorities and comparable institutions. No sale to private individuals!

Login
In stock - available for delivery within a few days
This item is transported on a pallet; additional shipping costs will be charged!
Download PDF

Description

APC Smart-UPS Rackmount

  • Begutachtung: CE, CE-Kennzeichnung
  • Batterietype: Wartungsfrei abgedichtete Bleisäurebatterie mit schwebendem Elektrolyt, auslaufsicher
  • Leistungsfaktor 1
  • integrierte Netzwerkschnittstelle mit Temparaturfühler und zusätzlichem Smartslot
  • Lieferumfang: Dokumentations-CD, Installationsanleitung, Abnehmbare Stützfüsse, Garantiekarte

>> ACHTUNG: Diese Anlage hat einen Einphasigen Anschluss über 16A / 3.6kW, klären Sie im Vorfeld den Anschluss mit dem Elektrounternehmen ab!

Specifications

Manufacturer
APC
Product group
USV
Product type
UPS Online, Rackmount
Colour
black
Classification (IEC 62040-3)
VFI-SS-111
UPS technology
Online
Output (VA/W)
6000 / 6000
Backup time full/half-load
1.5 / 8 min
Dimensions (HxWxD)
174 x 432 x 719 mm; 4 U
Mounting form
19" Rackmount
Voltage (input)
230 V
Voltage (output)
230 V
Frequency
50Hz
Connector type (input)
Festanschluss (Hard Wire 3 wire (1PH+N+G)
Connector type (output)
6 x IEC320 C13; 4 x IEC320 C19
Phase in/output
230V/230V / 50Hz
Delay expansion unit
10 x SRT192RMBP 19.29.3067
Interface
RJ-45 10/100 Base-T, RJ-45 seriell, SmartSlot, USB
USB 2.0 Interface
ja
Hot swap batteries
Ja, Frontseite
Bypass
automatisch + manuell
Activity Display
Ja
Internal cooling
Aktiv, Lüfter
Ambient temperature
0-40°C
Operating temperature min.
0 °C
Operating temperature max.
40 °C
Height
174 mm
Width
432 mm
Depth
719 mm
Weight
67 kg
Height of packaging (single piece)
400 mm
Width of packaging (single piece)
620 mm
Depth of packaging (single piece)
950 mm
Package weight (single piece)
70 kg

Downloads

Manufacturer data sheet - Betriebsanleitung SRT5 / SRT6 - Deutsch (697.2 KB) Safety instructions - Deutsch - English - Français - Italiano (189.1 KB)
