Please log in to see our prices and to be able to order. Delivery only to industry, trade, crafts, public institutions, authorities and comparable institutions. No sale to private individuals!
Login| Item no. | 19272203 |
|---|---|
| Brand / Manufacturer | APC |
| Manuf. item no. | SMT2200RMI2UNC |
| EAN | 0731304327691 |
| Item weight | 49 kg |
:strip_icc():strip_exif()/logos/apc.png "APC")
| Manufacturer | APC |
|---|---|
| Product group | USV |
| Product type | UPS Line Interactive, Rackmount |
| Colour | black |
| Scope of delivery | USV, Kabelsatz, PowerChute USV Management Software |
| Classification (IEC 62040-3) | VI-SS-333 |
| UPS technology | Line Interactive |
| Output (VA/W) | 2200 / 1980 |
| Backup time full/half-load | 5 / 8 min |
| Dimensions (HxWxD) | 86 x 480 x 683; 2 U |
| Mounting form | 19" Rackmount |
| Voltage (input) | 160 - 286 V |
| Voltage (output) | 230V |
| Output voltage regulation | ja |
| Frequency | 50 Hz +- 3% |
| Connector type (input) | Kaltgeräte IEC320 C20 |
| Connector type (output) | 8 x Kaltgeräte IEC320 C13; 1 x Kaltgeräte IEC320 C19 |
| Phase in/output | 230V/230V / 50Hz |
| Over current protection | EMI,- RFI-Filter |
| Delay expansion unit | nein |
| Slot for adapter card | 1 Smartslot mit AP9631 Network Management Card |
| Interface | RS232, USB, AP9631 Netzwerkkarte |
| RS-232 Interface | ja |
| USB 2.0 Interface | ja |
| Hot swap batteries | Ja, Frontseite |
| Bypass | nein |
| Additional over current protector | nein |
| Activity LED | 16 LED |
| Activity Display | nein |
| incl.Management Software | Windows |
| Internal cooling | Aktiv, Lüfter |
| Ambient temperature | 0-40°C, Batterie 20-25°C |
| Height | 86 mm |
| Width | 480 mm |
| Depth | 683 mm |
| Weight | 43 kg |
| Height of packaging (single piece) | 0 mm |
| Width of packaging (single piece) | 0 mm |
| Depth of packaging (single piece) | 0 mm |
| Package weight (single piece) | 49 kg |
:strip_icc():strip_exif()/cms_secde/cms/ueber_uns/markenwelt/hersteller_logos/apc_lifeison_logo.png){kind=logo}
Over the past four decades, APC has become the industry standard for reliable power and physical IT infrastructure. In 2007, APC was acquired by Schneider Electric, a multinational European company known worldwide for its expertise in energy management and automation.
