- Manufacturer
-
ATEN
- Product group
-
Steckdosenleisten
- Product type
-
IP Power Switch
- Colour
-
black
- Scope of delivery
-
1x Stromverteilungseinheit PG98230
1x Rackmontagesatz
1x RJ-45- zu DB-9-Kabel
1x vollflächiger farbiger Aufkleber
1x Gebrauchsanweisung
- Function
-
Fernschaltung über IP
- Max. capacitance
-
16A
- Max. voltage
-
230V
- Switch type
-
IP
- Number of socket pots
-
30
- Quantity of outputs/angles
-
(6) IEC 60320 C19, (24) IEC 60320 C13
- Socket type
-
- IEC320 C13, Kaltgeräte, 10A
- IEC320 C19, Kaltgeräte, 16A
- Material (casing)
-
Metall
- Colour (Design profile)
-
schwarz
- Connection cable
-
IEC60309
- Connector plug
-
IEC 309 16/20A Red 3P+N+PE
- Plug type
-
CEE rot 16A 3P+N+PE 400V "Drehstromstecker"
- Regional use
-
Ohne Einschränkung
- Mains connection
-
CEE Stecker 3Ph. IEC 309
- Operating temperature min.
-
0 °C
- Operating temperature max.
-
60 °C
- Storage temperature min.
-
-20 °C
- Storage temperature max.
-
60 °C
- Height
-
1790 mm
- Width
-
56 mm
- Depth
-
68 mm
- Weight
-
7.36 kg
- Height of packaging (single piece)
-
150 mm
- Width of packaging (single piece)
-
240 mm
- Depth of packaging (single piece)
-
1940 mm
- Package weight (single piece)
-
10.171 kg
- Output alignment
-
straight, backside
- Technical particularity
-
--
