D-Link BCD-P01 Outdoor Dome Kamera, 2 Megapixel H.265

Item no. 25150980 Brand / Manufacturer D-LINK Manuf. item no. BCD-P01 EAN 790069482199
D-LINK
New products

Please log in to see our prices and to be able to order. Delivery only to industry, trade, crafts, public institutions, authorities and comparable institutions. No sale to private individuals!

Login
Deliverable approx. 08/10/2026
Download PDF

Description

2 Megapixel H.265 Outdoor Dome Kamera

  • 2MP progressive CMOS sensor
  • IR range up to 30 m
  • Minimum object distance of 1 m
  • IP66 weather protection
  • IK10-certified impact protection
  • 10/100 Fast Ethernet with 802.3af PoE
  • microSD card support up to 1 TB
  • Detection of people, vehicles, motion and IVS
  • Integrated people counting
  • ONVIF Profile S/T compatible

Clear, high-resolution video quality
Delivers crystal-clear, high-resolution video, ensuring that every image is clear, vivid and reliable in any environment

Intelligent video analytics
Advanced video analytics reduce false alarms and enable precise real-time monitoring and proactive security

Simplified cabling
PoE enables power and data transmission via a single cable, reducing installation effort and costs

IK10 protection
Meets the highest impact resistance rating (IK10), making the camera resistant to heavy impacts and attempts at vandalism

Digital Wide Dynamic Range
Captures objects accurately in challenging lighting conditions, ensuring optimal visibility in both bright and dark areas

IP66 weather protection
Ensures reliable protection against dust and water, even under extreme outdoor conditions

Translated with DeepL.com (free version)

Specifications

Manufacturer
D-LINK
Product group
Security Cameras
Product type
Fixed-Dome Network Camera
Colour
white
Mounting form
Fixed-Dome
Interface
LAN
ONVIF
yes
Image Sensor Type
1/3” Progressive CMOS sensor
Resolution
2 MPx
Video Compression
H.265/H.264/MJPEG
Lens Type
Fixed Lens
Horizontal viewing angle
93.1 °
Viewing angle vertical
52.2 °
IR LED
yes
IR range (max.)
30 m
WDR
DWDR
Pan Area
0° – 355°
Tilt Area
0° – 75°
Motion Detection
yes
Memory Card Slot
yes
Power over Ethernet (PoE)
yes
Protection class (IP Code)
  • IP66
  • IK10
Suitable for Outdoor Use
yes
Mains connection
Power over Ethernet (PoE)
Operating temperature min.
-25 °C
Operating temperature max.
55 °C
Height
85.4 mm
Width
110 mm
Depth
110 mm
Weight
405 g
Height of packaging (single piece)
0 mm
Width of packaging (single piece)
0 mm
Depth of packaging (single piece)
0 mm
Package weight (single piece)
0 kg

Downloads

Manufacturer data sheet - English (450.8 KB) Manufacturer data sheet - Deutsch (288.0 KB) User manual - English (22.6 MB) Quick Installation Guide - English (886.7 KB)
