D-Link DAP-E3620OU Wi-Fi 7 Access Point

Item no. 21182545 Brand / Manufacturer D-LINK Manuf. item no. DAP-E3620OU EAN 790069482298

Please log in to see our prices and to be able to order. Delivery only to industry, trade, crafts, public institutions, authorities and comparable institutions. No sale to private individuals!

Deliverable approx. 01/04/2027

Download PDF

Description

Nuclias Connect BE3600 Wi-Fi 7 Outdoor Access Point

Wi-Fi 7 2x2 + 2x2 dual-band BE3600 solution
Multi-Link Operation (MLO) improves transmission efficiency and connection stability
4096-QAM modulation enhances data throughput and spectrum efficiency
IP67-rated protection, dustproof, waterproof, and weather-resistant
Ruggedised outdoor enclosure designed for reliable 24/7 operation in all weather conditions
Supports wall mounting and pole mounting for outdoor installation
Each SSID can be configured with a dedicated captive portal page
Customisable login pages for branding, advertising, or promotional purposes
Supports Nuclias Unity, Nuclias hardware controller, and Nuclias software controller for centralised management, monitoring, and maintenance
Provides flexible deployment options with centralised cloud or on-premises management
Latest WPA3 Personal/Enterprise encryption
Supports 802.1x and MAC/IP ACL
Establish complete security protection for wireless network

Specifications

Manufacturer: D-LINK
Product group: Network Components
Product type: Access Point
Colour: white
Scope of delivery: DAP-E3620OU, Pole Mounting Clamp x2, Waterproof Cable Gland x2, Quick Start Guide
WiFi standard: WiFi 7 (IEEE 802.11be)
Maximum data transfer rate: 3600 Mbit/s
Wi-Fi frequency band: Dual-Band
2.4 GHz data transfer rate: 688 Mbit/s
5 GHz data transfer rate: 2882 Mbit/s
WLAN WPA encryption: yes
WLAN WPA2 encryption: yes
WLAN WPA3 encryption: yes
Interface: 1x 2.5 Gigabit Ethernet PoE LAN port, 1x 1 Gigabit LAN port
Power over Ethernet (PoE): yes
Power supply: External power supply unit
Power consumption Maximum: 20 W
Protection class (IP Code): IP67
Operating temperature min.: -30 °C
Operating temperature max.: 55 °C
Storage temperature min.: -40 °C
Storage temperature max.: 70 °C
Height: 88 mm
Width: 304 mm
Depth: 181 mm
Weight: 1600 g
Height of packaging (single piece): 0 mm
Width of packaging (single piece): 0 mm
Depth of packaging (single piece): 0 mm
Package weight (single piece): 0 kg
