METZ CONNECT E-DAT M12 X-codiert, feldkonfektionierbarer Stecker

Item no. 21173105 Brand / Manufacturer METZ CONNECT Manuf. item no. MNF881A315-0001 EAN 4250184151166 Item weight 0.036 kg
METZ CONNECT

Please log in to see our prices and to be able to order. Delivery only to industry, trade, crafts, public institutions, authorities and comparable institutions. No sale to private individuals!

Login
Deliverable approx. 11/02/2026
Download PDF

Description

Feldkonfektionierbarer M12 Cat.6A Stecker X-kodiert auf Basis IEC PAS 61076-2-109

Feldkonfektionierbarer M12-X Cat.6a Stecker; 10GBit geeignet nach IEEE 802.3an; geeignet für POE; 8adriger M12-Stecker für AWG22; Anschluss von AWG 26/7-22/7; AWG 24/1- 22/1 möglich; Volldraht CU-Leiterdurchmesser 0,4-0,64mm; Litze CU-Leiterdurchmesser 0,48-0,76mm; Aderdurchmesser bis 1,6mm; Kabelmantel 5,0 bis 9,7mm; besteht aus 2 Teilen; einfachste Konfektionierung ohne Spezialwerkzeug; industrietaugliches Zinkdruckgussgehäuse

Specifications

Manufacturer
METZ CONNECT
Product group
Anschlusstechnik TP
Product type
Steckverbinder M12 X-codiert
Colour
silver
Transfer quality
Cat6A / Class EA
Operating temperature min.
-40 °C
Operating temperature max.
85 °C
Height
16.8 mm
Width
16.8 mm
Depth
52 mm
Weight
26 g
Height of packaging (single piece)
30 mm
Width of packaging (single piece)
90 mm
Depth of packaging (single piece)
150 mm
Package weight (single piece)
0.036 kg

Downloads

Manufacturer data sheet - Français (1.7 MB) Manufacturer data sheet - Deutsch (1.7 MB) Manufacturer data sheet - English (1.7 MB)
