ROLINE 19" Wall Cabinet Basic Plus 12U, 600x600 BxT black

Item no. 26210291 Brand / Manufacturer ROLINE Manuf. item no. 26.21.0291 EAN 7630049602946 Item weight 21 kg

ROLINE 19" Wall Cabinet Basic Plus 12U, 600x600 BxT black

Please log in to see our prices and to be able to order. Delivery only to industry, trade, crafts, public institutions, authorities and comparable institutions. No sale to private individuals!

Deliverable approx. 07/24/2026

This item is transported on a pallet; additional shipping costs will be charged!

Download PDF

Description

ROLINE 19 inch wall-mounted housing Basic Plus with 600 mm depth

The wall-mounted enclosures in the ROLINE Basic Plus series have been specially designed for flexible network cabling. This series represents an ideal balance between the ROLINE PRO and ROLINE Basic series. The base plate and the roof are equipped with a punched cable inlet. In addition, a punched-out area in the roof makes it possible to accommodate a fan module. Inside, a pair of galvanised profile rails with height units of 483 mm (19") are installed, which are also adjustable in depth. The robust steel constructions of the cabinets are made of strong sheet steel and are available powder-coated in grey (RAL 7035) or black (RAL 9005). The side panels are fitted with a quick-release fastener and are removable, which improves accessibility. An optional lock can also be installed in the side panels. Wall mounting is carried out in two simple steps: Firstly, the rear panel is screwed to the wall and then connected to the housing. Optional levelling feet or castors can be used to make the cabinets free-standing.

Load capacity: 80 kg
Front door made of tempered glass, lockable
Side panels are fitted with a quick-release mechanism and are removable
Roof with cut-out for fan modules
Cable feed possible on roof and base
Ventilation slots for passive ventilation and air extraction
Incl. mounting material
IP protection class: IP20
Delivery: assembled

Specifications

Manufacturer: ROLINE
Product group: 19"- / 10" technology
Product type: 19"-wall housing
Colour: black
Scope of delivery: ROLINE 19 inch Wall Cabinet Basic Plus, earthing cable set, 2x spanners, assembly instructions
Type of profile rail: L-shaped
Modular spacing: 482.6 mm (19 inch)
Model: With permanent frame
Height units: 12 U
Minimum rack depth supported: 320 mm
Maximum rack depth supported: 450 mm
Delivery condition: fully assembled
Demountable: yes
Material group: Steel
Material front door: Glass
Wall mountable: yes
Adjustable feets: no
Maximum weight capacity: 80 kg
Protection class (IP Code): IP20
Soundproof: no
Number of doors: 1
With front door: yes
With backside door: no
With glazed door: yes
Front: Glass door
Rack rails: yes
Side panels included: yes
Removeable side panels: yes
Removable front door: yes
Removable back door: no
Ventilation: Passive
RAL colour: RAL 9005 Jet black
Height: 645 mm
Width: 600 mm
Depth: 600 mm
Weight: 19.2 kg
Height of packaging (single piece): 666 mm
Width of packaging (single piece): 630 mm
Depth of packaging (single piece): 935 mm
Package weight (single piece): 21 kg
