ROLINE ProSecure II 1500 RM2U - Online UPS, 19" Rack Version

Item no. 19401090 Brand / Manufacturer ROLINE Manuf. item no. 19.40.1090 EAN 7611990154906 Item weight 21.5 kg
ROLINE
Output (VA/W):
Interface:

Please log in to see our prices and to be able to order. Delivery only to industry, trade, crafts, public institutions, authorities and comparable institutions. No sale to private individuals!

Login
In stock - available for delivery within a few days
Ordered by 2 p.m. - usually shipped the same day
This item is transported on a pallet; additional shipping costs will be charged!
Download PDF

Description

The ROLINE ProSecure Series - for optimum power protection is a truly state of the art online double conversion UPS, ideal for all essential computer systems and servers. Protects against: power failure, power sag, power surge, under voltage, over voltage, switch transient, line noise, frequency variation, harmonic distortion.

Product features:
  • Cold start function (DC power on)
  • Lightning and surge protection
  • Battery replacement warning
  • Emergency Power Off function
  • Battery remain time display
  • LCD display front panel
  • Power factor correction
  • Support USB communication
  • Multiple language LCD display
  • On line output voltage selected
  • Hot swappable battery by user
  • True on-line technology provides all power protection
  • Pure sine-wave output with less than 3% THD
  • Fully digitized microprocessor controlled
  • Short Circuit and overload protection
  • Advanced

Specifications

Manufacturer
ROLINE
Product group
UPS
Product type
UPS Online, Rackmount
Colour
grey
Scope of delivery
UPS, Software, Cable Set
Classification (IEC 62040-3)
VFI-SS-111
UPS technology
Online
Power class
1000 ... 1900 VA
Output (VA/W)
1500 / 1050
Efficiency
95 %
Backup time
5 min
Backup time full/half-load
5 / 10 min
Dimensions (HxWxD)
88 x 428 x 425 mm; 2 HE
Mounting form
19" Rackmount
Voltage (input)
160-230V
Voltage (output)
230V
Output voltage regulation
± 2%
Frequency
50Hz ± 3%
Connector type (input)
cold connector IEC 320 C14
Outputs
4
Connector type (output)
4x cold connector IEC 320 C13
Phase in/output
230V/230V / 50Hz
Over current protection
EMI,- RFI-Filter
Max. quantity of delay expansion units
2
Slots for adapter card
1
Interface
RS232, USB
RS-232 Interface
yes
USB 2.0 Interface
yes
Hot swap batteries
Yes, front side
Bypass
Automatic + manual
Additional over current protector
no
Activity
Display
Activity LED
5
Activity Display
LCD
incl.Management Software
Windows
Internal cooling
Active, fan
Ambient temperature
0-40°C
Mains connection
Cold appliance connection
Battery category
Industrial battery
Number of batteries
3 pieces
Battery Voltage
12 V
Battery Capacity
9 Ah
Battery type
Pack
Battery
built-in
Battery technology
Lead-acid
Operating temperature min.
0 °C
Operating temperature max.
40 °C
Height
88 mm
Width
428 mm
Depth
425 mm
Weight
18 kg
Height of packaging (single piece)
200 mm
Width of packaging (single piece)
550 mm
Depth of packaging (single piece)
550 mm
Package weight (single piece)
21.5 kg
Delay expansion unit
2
Slot for adapter card
1
Conformity
CE
Back up time
Power rating (VA / W)
with 0 / 1 / 2 Battery pack (min)
1500/1050
5 / 13 / 28
1350/945
6 / 16 / 34
1200/840
7 / 20 / 40
1050/735
9 / 25 / 48
900/630
11 / 30 / 56
750/525
14 / 37 / 66
600/420
19 / 45 / 85
450/315
27 / 60 / 140
300/210
40 / 100 / 220
150/105
60 / 270 / 400

Downloads

Product data sheet - English (41.8 KB) User manual - Deutsch (9.8 MB) User manual - English (9.8 MB) Safety instructions - Deutsch - English - Français - Italiano (189.1 KB)
