TELEGÄRTNER STX V1 bulkhead set, LC duplex adaptor, multimode

Item no. 21173192 Brand / Manufacturer TELEGÄRTNER Manuf. item no. 100007578 EAN 4018359329167 Item weight 0.019 kg
TELEGÄRTNER

Please log in to see our prices and to be able to order. Delivery only to industry, trade, crafts, public institutions, authorities and comparable institutions. No sale to private individuals!

Login
In stock - available for delivery within a few days
Ordered by 2 p.m. - usually shipped the same day
Download PDF

Description

STX V1 bulkhead set LC duplex adaptor, multimode

  • storage of cables with diameter 5...10 mm
  • simple mounting of bulkheads through a central screwed gland or four screws
  • NBR aiguilette at the protection cap
  • bay for marking labels
  • with bend protection to prevent cables from being excessively bent
  • rugged zinc diecast or plastic housing
  • protection class IP67
  • Variant 1 acc. to IEC 61076-3-106
  • pre-assembled plugs and set products for simple assembly
  • available with RJ45 Cat.6A, Cat.6 Class EA, USB or FO insert

Specifications

Manufacturer
TELEGÄRTNER
Product group
Connection technology FO
Product type
Fibre Optic Adapters
Colour
black
Component-Level certified
yes
Quantity of ports
1
Material (casing)
plastic
Protection class (IP Code)
IP67
Operating temperature min.
-20 °C
Operating temperature max.
80 °C
Storage temperature min.
-40 °C
Storage temperature max.
90 °C
Height
32 mm
Width
32 mm
Depth
22.8 mm
Weight
80 g
Height of packaging (single piece)
30 mm
Width of packaging (single piece)
100 mm
Depth of packaging (single piece)
160 mm
Package weight (single piece)
0.019 kg

Downloads

Manufacturer data sheet - Deutsch (113.5 KB) Manufacturer data sheet - English (113.5 KB)

Product security

Information in accordance with the EU Product Safety Regulation, (GPSR):


Telegärtner Karl Gärtner GmbH
Lerchenstr. 35, 71144 Steinenbronn, Germany
