TP-Link Omada BE9300 Ceiling Mount Tri-Band Wi-Fi 7 Access Point. 2.4 GHz, 5 GHz, 6 GHz, Maximum data transfer rate: 9300 Mbit/s. Security algorithms: SNMP, SNMPv2, SNMPv3, WPA-Enterprise, WPA-Personal, WPA2-Enterprise, WPA2-Personal,.... Ethernet LAN data rates: 2500 Mbit/s. Product colour: White
Ultra-Thin Enterprise WiFi 7 Access Point
- Next-Gen WiFi 7
- Wi-Fi Speeds up to 9214 Mbps
- Multi-Link Operation (MLO)
- 1× 2.5G RJ45 Port
- PoE Power
- Ultra-Thin Design
- Centralized Cloud Management
- Omada Mesh Technology
Ultra-Thin Design for Flexible Deployment
The overall design of EAP772 utilizes a thinner circular arc with a groove around the top cover, fitting closer to various installation surfaces such as ceilings. The compact internal hardware layout and heat-dissipating design ensure high performance with a sharp aesthetic.
Boosted Network Security
- Secure Guest Network with up to 24 SSIDs
- Boost Your Business with SMS Login
- WPA3 for Worry-Free Open Public Networks
- Rogue AP Detection
Specifications
- Manufacturer
- TP-LINK TECHNOLOGIES
- Product type
- Wireless Access Points
- Ethernet LAN (RJ-45) ports
- 1
- Width
- 220 mm
- Depth
- 220 mm
- Height
- 32.5 mm
- Operating relative humidity (H-H)
- 10 - 90%
- Operating temperature (T-T)
- 0 - 40 °C
- Storage temperature (T-T)
- -40 - 70 °C
- Storage relative humidity (H-H)
- 5 - 90%
- Security algorithms
- SNMP, SNMPv2, SNMPv3, WPA-Enterprise, WPA-Personal, WPA2-Enterprise, WPA2-Personal, WPA3-Enterprise, WPA3-Personal
- MAC address filtering
- Yes
- Service Set Identifier (SSID) features
- Multiple SSIDs
- Number of SSID supported
- 24
- Remote Authentication Dial-In User Service (RADIUS)
- Yes
- Access Control List (ACL)
- Yes
- Certification
- CE, FCC, RoHS, IC
- Web-based management
- Yes
- Quantity per pack
- 1 pc(s)
- AC adapter included
- No
- Mounting kit
- Yes
- Antenna type
- Internal
- Placement
- Ceiling, Wall
- Product colour
- White
- LED indicators
- Yes
- 2.4 GHz
- Yes
- 5 GHz
- Yes
- 6 GHz
- Yes
- Maximum data transfer rate
- 9300 Mbit/s
- Maximum data transfer rate (2.4 GHz)
- 574 Mbit/s
- Maximum data transfer rate (5 GHz)
- 2880 Mbit/s
- Maximum data transfer rate (6 GHz)
- 5760 Mbit/s
- Ethernet LAN data rates
- 2500 Mbit/s
- Networking standards
- IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11be, IEEE 802.11g, IEEE 802.11n
- Number of users
- 380 user(s)
- Bluetooth
- Yes
- Bluetooth version
- 5.2
- MIMO
- Yes
- MIMO type
- Multi User MIMO
- VLAN support
- Yes
- Airtime Fairness (ATF)
- Yes
- Quality of Service (QoS) support
- Yes
- BeamForming
- Yes
