ROLINE External Type M.2 NVMe SSD Enclosure with USB 3.2 Gen 2x2 Type C

Please log in to see our prices and to be able to order. Delivery only to industry, trade, crafts, public institutions, authorities and comparable institutions. No sale to private individuals!

Available - can be delivered within 24 hours

Ordered by 2 p.m. - usually shipped the same day

Item no.	16014147
Brand / Manufacturer	ROLINE
Manuf. item no.	16.01.4147
EAN	7630049617544
Item weight	0.02 kg

Description

Extra narrow empty housing made of matt aluminium for M.2 SSDs, for connection via USB 3.1 / USB 3.2 Gen 2 Type C

Empty housing for M.2 SSDs with USB Type C connector
External interface: USB type C
Compatible with USB 3.1 / USB 3.2 Gen 2x2 with data transfer rates up to 20 Gbps
Supports M.2 SSDs 2230, 2242, 2260, 2280 (M key)
Matt, silver aluminium housing

Note: According to the current specifications of USB.org we have adapted the technical data of our USB 3 products. The new designation for the already known USB specifications has been changed to USB 3.2 Gen 1 (formerly USB 3.0 / USB 3.1 Gen 1) and USB 3.2 Gen 2 (formerly USB 3.1 / USB 3.1 Gen 2).

Specifications

Manufacturer	ROLINE
Product group	Drive housing
Product type	M.2 SSD Enclosure
Colour	anthracite
Scope of delivery	M.2 SSD Enclosure, manual, USB Type C cable
Quantity of Drives	1
Drive form	M.2
External connections	USB 3.2, Gen2x2, Type C
Dimensions (HxWxD)	15 x 46 x 118.5 mm
Material (casing)	Aluminium
Power supply	over USB port
Height	15 mm
Width	46 mm
Depth	118.5 mm
Weight	111.6 g
Height of packaging (single piece)	20 mm
Width of packaging (single piece)	100 mm
Depth of packaging (single piece)	100 mm
Package weight (single piece)	0.02 kg

Downloads

Product data sheet - English (53.4 KB)

Download
