Description

SMART stekkerdoos in robuust design

Kunststof stekkerdoos 6-voudig, geschroefd
Contacten 35° gedraaid
Met geïntegreerde contactbeveiliging en schakelaar
Overspanningsbeveiliging met 5kA nominale lekstroom
3 varistoren, temperatuurzekering en optisch
storingsindicator
Technische specificaties:

• Schakelaar, 2-polig, verlicht
• Kleur wit
• Kabel: H05VV-F 3G 1,50 mm² met veiligheidsstekker
• Kabellengte: 1,5 m
• Maximale belasting: 10/16A 3600W

• Eenvoudige bevestiging door middel van schroefgaten
• Handig opbergen van snoeren

Specifications

Manufacturer	BACHMANN
Product group	Power Bars
Product type	Power strip
Colour	white
Length	1.5 m
Function	Stekkerdoos met overspanningsbeveiliging
Mounting form	Desktop
Max. capacitance	3600W
Max. voltage	250V AC
ON/OFF Switch	yes
Switch type	2 Pol. verlicht
Number of socket pots	6
Quantity of outputs/angles	6 / 35°
Output alignment	6 Rijen
Socket type	3P. German, CEE 7/3, Type-F
Material (casing)	Kunststof
Connection cable	1,5 m
Colour (Cable)	white
Connector plug	Schuko
Plug type	3P. German, CEE 7/7, Type-E/F
With enhanced contact protection	yes
Over voltage-/surge protection	yes
Regional use	Germany, Austria, Netherlands
Height	41 mm
Width	370 mm
Depth	56 mm
Weight	0.52 kg
Height of packaging (single piece)	60 mm
Width of packaging (single piece)	150 mm
Depth of packaging (single piece)	420 mm
Package weight (single piece)	0.514 kg

Downloads

Manufacturer data sheet - English (127.7 KB)

Download

Safety instructions - Deutsch - English - Français - Italiano - Español (467.0 KB)

Download

Accesories

BACHMANN screw mount, Screw mount for SMART Line white

Item no.:	19073802
Manuf. item no.	919.273

None EUR incl. VAT
