TRENDnet TEG-S24G Unmanaged Gigabit Ethernet Switch, 24-Port, GREENnet Technology
Please log in to see our prices and to be able to order. Delivery only to industry, trade, crafts, public institutions, authorities and comparable institutions. No sale to private individuals!
LoginDescription
The TRENDnet TEG-S24G is a high-performance 24-port Gigabit GREENnet switch designed for reliable networking in offices and home environments.
- 24 Gigabit Ethernet ports
- 48 Gbps switching capacity
- Fanless design for silent operation
- Dimensions: 440 × 210 × 45 mm
- Supports Jumbo Frames
- Durable metal housing with included 19" rack mounting brackets
- GREENnet technology reduces power consumption by up to 70%*
- Limited Lifetime Warranty*
- GREENnet technology reduces power consumption by up to 70%*- 24 x Gigabit Auto-MDIX RJ-45 ports- Sturdy metal rackmount switch with built in power supply- 48Gbps forwarding capacityThe 24-Port Gigabit GREENnet Switch, model TEG-S24g, provides high bandwidth performance, ease of use and reliability, all while reducing power consumption by up to 70%.GREENnet technology automatically adjusts power voltage as needed, resulting in substantial energy savings. Embedded GREENnet technology works right out of the box with no management requirement.Boost office network efficiency and eliminate network congestion with Gigabit speeds and a total switching capacity of 48Gbps with Full-Duplex mode. A built in universal power supply reduces cable clutter and diagnostic LEDs help with network troubleshooting. Plug and Play this sturdy metal switch for reliable high-speed network connectivity.
Specifications
- Manufacturer
- TRENDNET
- Product group
- Network Switches
- Product type
- Network Switch
- Colour
- black
- Scope of delivery
- TRENDnet TEG-S24G 24-Port Gigabit GREENnet Switch, Quick Installation Guide, Power cord, Rack mounting kit
- Network standard
- Gigabit Ethernet
- LAN (Mbps)
- 10/100/1000
- Quantity of ports
- 24
- Fast Ethernet Ports RJ-45
- 24
- Gigabit Ethernet Ports RJ-45
- 24
- Dimensions (HxWxD)
- 440 x 210 x 45 mm
- Mains connection
- Cold appliance connection
- Height
- 440 mm
- Width
- 210 mm
- Depth
- 45 mm
- Weight
- 2867.37 g
- Height of packaging (single piece)
- 300 mm
- Width of packaging (single piece)
- 560 mm
- Depth of packaging (single piece)
- 90 mm
- Package weight (single piece)
- 3.23 kg
- Basic switching RJ-45 Ethernet ports quantity
- 24
- Weight
- 1.7 kg
- Input voltage
- 100-240 V
- Power consumption (typical)
- 13 W
- Operating temperature (T-T)
- 0 - 40 °C
- Storage temperature (T-T)
- -10 - 70 °C
- Supported network protocols
- CSMA /CD, Star
- Networking standards
- IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
- 10G support
- N
- Full duplex
- Y
- Flow control support
- Y
- Auto MDI/MDI-X
- Y
- MAC address table
- 8000 entries
- Switching capacity
- 48 Gbit/s
- Supported data transfer rates
- 10, 20, 100, 200, 2000
- Maximum data transfer rate
- 2 Gbit/s
- Jumbo frames support
- Y
- Switch type
- Unmanaged
- Dimensions (WxDxH)
- 280 x 180 x 44 mm
- Connectivity technology
- Wired
- Wi-Fi
- Y
- Input frequency
- 50-60 Hz
- Rack mounting
- Y
- Stackable
- N
- Product colour
- Black
- Housing material
- Metal
- LED indicators
- Y
- Power over Ethernet (PoE)
- N
- Harmonized System (HS) code
- 85176990
