TRENDnet TPE-5240WS Gigabit Ethernet (10/100/1000), Energie Über Ethernet (PoE) Unterstützung 1U Schwarz Netzwerk-Switch

Please log in to see our prices and to be able to order. Delivery only to industry, trade, crafts, public institutions, authorities and comparable institutions. No sale to private individuals!

Deliverable approx. 05/20/2024

Item no.	21221320
Brand / Manufacturer	TRENDNET
Manuf. item no.	TPE-5240WS
EAN	710931161144
Item weight	7.43 kg

Description

52-Port Gigabit Web Smart PoE+ Switch

Der 52-Port Gigabit Web Smart PoE+ Switch von TRENDnet, Modell TPE-5240WS, bietet fortschrittliche Verwaltungsfunktionen mit einer Schaltkapazität in Höhe von 104Gbps. Dieser rackmontierbare, IPv6-fähige Switch verfügt über eine intuitive webbasierte Oberfläche. Mit fortschrittlichen Verkehrsmanagementkontrollen, Fehlersuche und SNMP-Überwachung ist dieser Switch eine leistungsstarke Lösung für SMB-Netzwerke. Der TPE-5240WS verfügt über 48 Gigabit PoE+ Ports mit einer Gesamtleistung in Höhe von 370W sowie vier geteilte Gigabit-Ports (RJ-45 oder SFP). Der PoE+ Standard liefert bis zu 30W Leistung je Port für Geräte mir hohem Stromverbrauch wie Wireless Access Points, PTZ (Schwenk-/Neige-/Zoom-) Internetkameras und VoIP Telefonanlagen.

48 x Gigabit PoE+ Ports
4 geteilte Gigabit-Ports (RJ-45 oder SFP)
370 Watt PoE-Gesamtleistung
Leicht zu bedienende webbasierte Verwaltungsoberfläche
Unterstützt IPv6, LACP, VLAN, QoS und IGMP Snooping
Bandbreitenkontrolle je Port
Unterstützt privates VLAN und Voice VLAN
Intelligente Lüftung
104 Gbit/s Schaltkapazität
IEEE 802.1p QoS mit Warteschlangenplanung

TRENDnet’s 52-Port Gigabit Web Smart PoE+ Switch, model TPE-5240WS, delivers advanced management features with a 104Gbps switching capacity. This rack mountable IPv6 ready switch comes with an intuitive web-based interface. Advanced traffic management controls, troubleshooting, and SNMP monitoring make this a powerful solution for SMB networks. The TPE-5240WS provides 48 gigabit PoE+ ports with a total power budget of 370W, and four shared gigabit ports (RJ-45 or SFP). The PoE+ standard supplies up to 30W of power per port for devices such as high power wireless access points, PTZ (Pan Tilt Zoom) Internet cameras, and VoIP telephony systems. Web Smart Management Provides an easy-to-use web-based GUI management for reduced switch configuration complexity and offers a combination of SMB management features for easy deployment. Integration Flexibility Managed features include access control lists, VLAN, IGMP snooping, QoS, RMON, SNMP trap, and syslog for monitoring and flexible network integration. PoE Power A 370W PoE power budget supplies power to PoE/PoE+ devices.

Specifications

Manufacturer	TRENDNET
Product group	Netzwerk-Switches
Product type	Netzwerk-Switches
Colour	black
Scope of delivery	• TPE-5240WS • Snelle installatiemogelijkheid • CD-ROM (hulpprogramma en handleiding) • Stroomkabel (1,8 m/6 ft) • Framemontagekit
Quantity of ports	52
Free slots for SFPs	4
Power over Ethernet (PoE)	PoE+
Quantity of PoE ports	48
Max. PoE output power (total)	370 W
Dimensions (HxWxD)	440 x 430 x 44 mm (17,3 x 17 x 1,74 inch)
Mains connection	Kaltgeräte-Anschluss
Height	440 mm
Width	430 mm
Depth	44 mm
Weight	6.12 kg
Height of packaging (single piece)	110 mm
Width of packaging (single piece)	550 mm
Depth of packaging (single piece)	530 mm
Package weight (single piece)	7.43 kg

System requirements

Compatible operating systems	Windows 10, 8.1, 8, 7, Vista, XP, Windows 2003/2008 Server

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Combo SFP ports quantity	4

Weight & dimensions

Width	440 mm
Depth	430 mm
Height	44 mm
Weight	6.12 kg

Power

AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power consumption (max)	479 W

Operational conditions

Operating temperature (T-T)	-5 - 50 °C
Operating relative humidity (H-H)	0 - 95%

Protocols

Management protocols	HTTP/HTTPS (SSL v2/3 TLS), SNMP v1, v2c, v3, RMON v1, IPv6

Networking

Networking standards	IEEE 802.1D,IEEE 802.1Q,IEEE 802.1ab,IEEE 802.1p,IEEE 802.1s,IEEE 802.1w,IEEE 802.1x,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3af,IEEE 802.3at,IEEE 802.3az,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z
10G support	N
Full duplex	Y
Head-of-line (HOL) blocking	Y
Port mirroring	Y
Link aggregation	Y
Broadcast storm control	Y
Spanning tree protocol	Y

Data transmission

MAC address table	16000 entries
Switching capacity	104 Gbit/s
Throughput	77.4 Mpps
Jumbo frames support	Y
Jumbo frames	10000

Packaging data

Cables included	AC
Quick start guide	Y
Rack mount kit	Y
Resource CD	Y

Security

Access Control List (ACL)	Y
Security algorithms	802.1x RADIUS
IGMP snooping	Y

Management features

Quality of Service (QoS) support	Y
MIB support	Y
Web-based management	Y

Design

Rack mounting	Y
Product colour	Black
Form factor	1U
LED indicators	Y
Housing material	Metal
Number of fans	3 fan(s)
Certification	CE, FCC

Power over Ethernet (PoE)

Power over Ethernet (PoE)	Y
Power over Ethernet plus (PoE+) ports quantity	48
Total Power over Ethernet (PoE) budget	370 W

Performance

Noise level	52.4 dB
Packet buffer memory	1.5 MB
Maximum data transfer rate	2000 Mbit/s
Mean time between failures (MTBF)	239897 h

Virtual LAN features

VLAN support	Y
Virtual LAN features	Private VLAN
Number of VLANs	256

Multicast features

Multicast support	Y
Multicast MAC address table	256 entries
